Dongfeng 6000 liters asphalt distributor truck

Asphalt pothole repair truck is a kind of pavement construction machinery,asphalt sprayer truck is the main equipment of highway, city roads, airports and ports construction.Our Intellectualized asphalt mixer truck is used for spraying asphalt on the prime coat, the water-proof layer and tack coat in high-graded road construction.It also can be used for bituminous pavement with the construction techniques of spreading in layers. Asphalt truck can spray hot asphalt, emulsified asphalt, modified asphalt and etc.

Dongfeng 6000 liters asphalt distributor truck

Model: CLW5120

Curb weight: 6340Kg

Overall dimension:   7980*2350*2750mm

Dongfeng asphalt distributor truck Chassis Configuration: Dongfeng 4x2 chassis EQ1125,single row cab with left/right hand drive optional and A/C,3.8m wheelbase,140~170HP Engine,6-speed gearbox with manual,front brige 2.7T/ rear brige 5.5T, 8.25R20 tire.

Asphalt chip sealing truck for sale Top Configuration:

1.asphalt pavement repair vehicle Tank valume:5~6T; ellipse asphalt tanker with 50mm thickness insulating layer.

2.asphalt spreader truck Equipped with Asphalt tank,Asphalt pump,Hydraulic drive motor,Hydraulic pump,Hydraulic system,Spraying system,Heating system,Burner,Heat conduction oil pump,Pneumatic circuit,Auto control system and Operation panel etc..

Bitumen asphalt liquid transport tanker truck Optional Configuration:

1. road clean asphalt truck Standard Configuration: ①. Asphalt pump model: QGB950 (high viscosity asphalt pump, 950L/minute); ②. Asphalt pump hydraulic drive motor model 05-110 - BD31;  ③. Hydraulic pump model: CBQ563 - L;  ④. hydraulic system adopts Shanxi Yuci; Control mode: manual control one-control-two;  ⑤. Sprinkle width 4.5-6m; 48 asphalt intelligent nozzle;  ⑥. Heating method: heat conduction oil automatic temperature;  ⑦. Burner: Italian imported G20;  ⑧. Heat conduction oil pump: 40-25-160 (domestic)

2.asphalt truck paver Intelligent configuration (domestic): ①. Asphalt pump model: QGB950 (high viscosity asphalt pump);  ②. Asphalt pump hydraulic drive motor model 05-130 - BD31; Hydraulic pump: CBQ563 -l; Hydraulic system: proportional valve (Taiwan EFBG - 03-160 - HF); Hydraulic system: Shanxi Yuci(reversing valve and relief valve); Radiator: Nison brand.  ③. Control mode: control system (German Siemens CLW-48-01), Computer intellectual control, 1 control 1;  ④. Sprinkle width 4.5-6m; 30~39 pcs asphalt intelligent nozzle;  ⑤. Heating method: heat conduction oil automatic temperature; Burner: G20 (Italy). Heat conduction oil pump adopts HeBei domestic,  ⑥. Gasoline engine: 5.5 kw.

3. asphalt primer truck Intelligent configuration (import): ①. Asphalt pump: Belgian TGGP - 185-125;  ②. Asphalt pump hydraulic drive motor model 05-90-BD31; Hydraulic pump: Germany rexroth; Hydraulic system:Taiwan proportional valve; Hydraulic system: Shanxi Yuci (reversing valve and relief valve); Radiator:Nison brand.  ③. Control mode: control system (German Siemens CLW-48-01); computer intellectual control, 1 control 1;  ④. Sprinkle width 4.5-6m; 30-39 pcs intelligent asphalt nozzle;

⑤. Hheating method:heat conduction oil automatic temperature;  Burner: G10 (Italy).  Heat conduction oil pump: HeBei domestic; ⑥. Gasoline engine: Honda 5.5 kw.

Asphalt pavement maintenance truck Series produced by our factory:Asphalt distribution truck, Road maintenance Truck, Macadam synchronous sealing layer truck and Slurry sealing layer truck.

Asphalt mixing truck optional Chassis Brands: ISUZU,Sinotruk,Shacman,Dongfeng,FAW,CLW,Fonton,JMC,JAC,Chang'an,Steyr,Iveco,Hongyan and North Benz etc.

Asphalt insulation tank truck Agitation tank capacity: 3-14 CBM

Truck for asphalt road Advantage is that a person can be done indoors of Intelligent Asphalt Distribution Truck, operation is simple, you only need set up distributing parameter on the control panel,and then you can begin the work.

We are a professional truck asphalt manufacturer and can produce all kinds of asphalt road truck .You can customize mini asphalt truck, we can satisfy all your requirements.Please feel free to contact me If you have any questions and want to have asphalt distributor truck  price(see left contact information).
