Dongfeng small fecal suction truck-china sewage collecting truck 2cbm

Vacuum fecal suction truck is used for sucking fecal,sewage,mud,liquid mixed with tiny granules,sewer sediments(such as: silt, stones, bricks and other big objects) and urban water wells. Sewage truck stailey steel tank is widely used in large, medium and small towns sanitation, municipal, agricultural and chemical industry, factories and mines enterprises, property management community,especially apply to transport household waste in residential area.

Dongfeng small fecal suction truck-china sewage collecting truck 2cbm

Model: CLW5040

Curb weight: 3090Kg

Overall dimension: 5510*1800*2020mm

Sewage tanker Chassis Configuration: Dongfeng Tuyi 4x2 chassis EQ1045,single row cab with left/right hand drive optional and A/C,2.8m wheelbase,112HP gasoline Engine,5-speed gearbox with manual,front brige 1.1T/ rear brige 3T,175R14LT 8PR tire.

Vacuum sewage suction tank Top Configuration:

1. Vacuum pump sewage tanks volume: 2m³, round tank is made by 5-6mm special steel plate

2. Vacuum tank for sewage: Equipped with vacuum pump(rating rotate speed=1400r/m,min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, clockwise,Time for full suction<5min.),sewage pipes,self-draining valve,liquid level tube for view window, vacuum pressure gage,overflow valve, PTO,transmission shaft, moisture separator,oil-gas separator,multiple directional control valve,cleaning equipment, pipe network system, high quality hydraulic system and so on.

3. Vacuum suction sewage tank can be lifted  up  45° by  double hydraulic cylinder, and the rear lid also can be opened, so the truck can dump the sewage directly through the rear lid out of the tank.

Fecal truck Optional Configuration: 1.The tank can be made by corrosion resistant plate or done professional anti-corrosion.2.We can use the brand of vacuum pump you specified.3.Cleaning function.

Fecal tanker truck Series produced by our factory: Sewage Suction Truck and Sewage Suction Cleaning Truck,Fecal  Suction Truck and Fecal  Suction Cleaning Truck.Sewage Trailer.

Fecal suction truck Optional Chassis Brands: ISUZU,Sinotruk,Shacman,Dongfeng,FAW,CLW,Fonton,JMC,JAC,Chang'an,Steyr,Iveco,Hongyan and North Benz etc.

Fecal tanker Tank capacity: 3-20CBM

Fecal suction tanker truck Advantage is Equipped with high efficiency pump and self-priming and self-draining system.

We are a professional china sewage collection truck manufacturer and can produce all kinds of sewage vacuum tank.You can customize 4x2 fecal suction tank truck, we can satisfy all your requirements.Please feel free to contact me If you have any questions and want to have fecal suction truck price(see left contact information).
